HILTI TE 70-AVR SDS MAX CORDED ROTARY HAMMER

Compare
Availability: Available on backorder

Combihammer

  • Weight according to EPTA Procedure 01/2003:  8.3 kg
  • Single impact energy:  11.5 J
  • Hammer drilling diameter range:  12 – 55 mm

Features:
  • High speed of rotation (360 rpm) for extra drilling performance
  • Optimised mechanical clutch for maximum torque transfer
  • Maximum user comfort thanks to low contact pressure and Active Vibration Reduction (AVR) system for low vibration
  • Centre of gravity close to the grip for optimum balance
  • Glass-fibre reinforced casing parts for ruggedness and long life
Applications:
  • Hammer drilling in concrete, masonry and natural stone from 12 – 150 mm in diameter
  • Drilling holes for heavy-duty anchors from 20 – 40 mm in diameter
  • Breaching and demolition with pointed and flat chisels
  • Drilling with high torque in wood and steel
  • Hammer drilling in concrete, masonry and natural stone with drill bits from 1/2″ – 6″ in diameter

Technical Data:

Weight according to EPTA Procedure 01/2003 : 8.3 kg
Single impact energy : 11.5 J
Hammer drilling diameter range : 12 – 55 mm
Optimum hammer drilling range : 20 – 40 mm
Hammer drilling RPM : 360 tours/minute
Full hammering frequency : 2760 impacts/minute
Functionality : Active Vibration Reduction (AVR), Chiselling
Triaxial vibration value for hammer drilling into concrete (ah,HD) : 10.8 m/s² 1
Dust removal system available : TE DRS-Y, TE DRS-D, TE DRS-BK
Triaxial vibration for chiselling in concrete : 9.0 m/s² 2
Dimensions (LxWxH) : 540 x 125 x 305 mm
