ORIGINAL YALE Surface Mounted Heavy Duty 80kg Fire Rated Door Closer C-77EN4 (Non-Hold Open)
Yale surface mounted door closer applicable for EN Size 4, manufactured as per the European standard 1154. Aluminium die cast body with standard arm. Suitable for Wooden and Aluminium frame doors. Non Handed door closer with adjustable closing and latching speed.
Certification:
– UL Listed.
– Conform to UL228 & UL10C
Passed Durability Test:
– 300,000 Cycles
– Easily Adjustable Arm Height
– Max Opening Angle 180°
– Maximum Door Width: 1100mm
– Maximum Door Weight: 80kg
– Reversible (Left/Right Hand Fixing)
Two Speed Valves:
– One to Control Closing Speed from 180° to 15°
– Second to Activate Final Latch from 15° to 0°
– Backcheck (BC): Optional
Specifications:
Model No.: EN4
Dimension: 182(L) x 53(W) x 60.5(H) mm
Max. Width of Door (mm): 1100
Max. Weight of Door (kg): 80
Arm Type: 12 Hold Open Arm
Torque Max: 37 NM
Option Features: BC Backcheck
Finishing: SB Silver
